Table housing IC/T 281825
- Large selection of products
- Stockable & individual orders
- Permanently low and transparent prices
Dimensions: 243 x 145 x 56mm
Color: Black, similar to RAL 9005
Protection class: IP65
NEMA: 3
Housing material: Extruded profiles: Al Mg Si 0.5 powder-coated; Die-cast corner parts: zinc die-cast ZnAl 4 Cu 1, powder-coated; Corner caps: PA-GF 15, corner part seal TPV/TPE; Foam rubber cord (EPDM) in profile groove; Details see Technical Information
Scope of delivery: 2 front profiles including seal, 2 side profiles including seal, 4 die-cast corners, 4 corner part seals, 4 cover caps, 16 screws, 4 rubber feet, please order front panels separately.
Note: The smooth outer surface of the front profiles can be used for mounting foils or membrane keyboards. Determination of the dimensions for the AP 50 profile cuts for special dimensions:Length of the AP 50 front profile = dimension A – 43 mmLength of the AP 50 side profile = dimension B – 45 mm
