Battery compartments, plastic, IP 65 / DIN EN 60529 BE-4MN-IP-7024

Dimensions: 578 x 478 x 100 mm Color: Light gray, similar to RAL 7035 Protection class: IP65 NEMA: 3 Housing material: Extruded profiles: Al Mg Si 0.5 powder-coated; Die-cast corner parts: zinc die-cast ZnAl 4 Cu 1, powder-coated; Corner caps: PA-GF 15, corner part seal TPV/TPE; Foam rubber cord (EPDM) in profile groove; For details see technical information Scope of delivery: 2 front profiles including seal, 2 side profiles including seal, 4 die-cast corners, 4 corner part seals, 4 cover caps, 16 screws, 4 rubber feet, please order front panels separately. Note: The smooth outer surface of the front profiles can be used for mounting foils or membrane keyboards. About the corner part: The corner part offers installation space for various plugs behind the removable covers (IP 40). A direct wall screw connection is invisibly integrated into the corner areas. Determination of the dimensions for the AP 100 profile cuts for special dimensions:Length of the AP 100 front profile = dimension A – 78 mmLength of the AP 100 side profile = dimension B – 78 mm
